| Rahmen: |
Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625Wh battery, Bosch Gen.4, motor cover, 4-bar suspension system, tapered 1 1/8" - 1.5" head tube, Boost 148x12mm with replaceable hanger, 140mm travel |
| Dämpfer: |
Suntour TriAir 3-CR, lockout |
| Gabel: |
SR Suntour Aion Air RC-PCS 27.5+, tapered alloy steerer, Boost 110x15mm thru axle, 35mm stanchions, 150mm travel |
| Motor: |
Bosch Performance CX, 4th generation mid-motor, 250W rated power, 75Nm of torque, 25km/h maximum assist |
| Display: |
Bosch Kiox Led display, USB charging port, Gorilla glass |
| Akku: |
Bosch Power Tube 625Wh with charger |
| Schaltwerk: |
SRAM SX Eagle, X-Actuation |
| Schalthebel: |
SRAM SX Eagle Trigger, Single-Click, X-Actuation, Matchmaker type |
| Kettenradgarnitur: |
FSA CK-745/IS, Bosch Gen.4, 32T with chainguard, for Boost |
| Kassette: |
SRAM 1210 Eagle, X-Glide, 11-50T, 12-speed |
| Kette: |
SRAM SX Eagle, PowerLink, FlowLink connector, 12-speed |
| Steuersatz: |
FSA NO.57B, 1 1/8" - 1.5", retainer bearings |
| Lenker: |
Oval Concepts 205 flat bar, 6061 alloy, ± 5mm rise, 9° sweep, 31.8mm clamp, width: 760mm |
| Griffe: |
WTB Waffel, Single lock-on, dual density Kraton |
| Vorbau: |
Oval Concepts 600AM, 3D-forged 6061 alloy, 0°, 31.8mm clamp, length: 17", 19" - 35mm, 21" - 45mm |
| Sattel: |
WTB High Tail Trail, Comp, e-Bike specific , steel rail |
| Sattelstütze: |
KS LEV-SI Dropper, 30.9mm, remote, travel: 17", 19" - 125mm, 21" - 150mm |
| Bremsen: |
TRP Slate-T4, 4-piston, hydraulic disc, 203mm rotors |
| Bremshebel: |
TRP Slate-T4, 2 finger lever |
| Radsatz: |
Formula e-MTB CL 32H hubs, WTB ST i35 TCS 2.0 double wall 27.5" rims, 14/15g stainless steel spokes |
| Reifen: |
Maxxis Minion DHF front, Minion DHR II rear, 27.5"x2.8", EXO, 60 tpi, Tubeless Ready |
|
|
| Gewicht: |
ca. 25,53 kg |
| max. zulässiges Gesamtgewicht: |
keine Angaben |
| Geometriedaten: |
siehe Artikelbilder/Artikelbeschreibung |
| Größe(n): |
17"/43cm, 19"/48cm, 21"/53cm |
| Farbe(n): |
Satin Red |
